Inverted Microscope 5x 10x 20x 40x

Inverted Microscope 5x 10x 20x 40x An inverted microscope with 5x, 10x, 20x, and 40x objectives is used for examining living cells and tissues in containers like Petri dishes by viewing them from below.

It is ideal for live cell imaging, cell culture, and observing biological processes in vitro, with increasing magnification revealing more detail, from low-power overview (5x) to cellular structure (40x).

For general live cell observation

• Inverted Biological Microscope:
  • Pros: Excellent for live cell imaging and observation in culture vessels, with the objective lenses positioned beneath the stage, making it easy to place large containers like Petri dishes on top. Offers a long working distance to view through thicker specimens.
  • Cons: The design makes it unsuitable for examining traditional, flat glass slides.
• Oxion Inverso Microscope:
  • Pros: Equipped for phase contrast, which is crucial for viewing unstained, living cells clearly. Allows for a manual, less-vibrating system suitable for delicate tasks like cell manipulation.
  • Cons: May require additional accessories for specific applications, such as a camera for documentation.
• Inverted Microscope with Camera Connection:
  • Pros: Can connect to SLRs, or other video cameras for photo and video documentation of living cells, their growth, and other dynamics. Ideal for time-lapse imaging.
  • Cons: Adds to the overall cost of the system.

For specialized biological applications

• Inverted Microscope for IVF:
  • Pros: Used in in-vitro fertilization (IVF) and developmental biology to observe and manipulate live cells or embryos.
  • Cons: Requires a very stable, vibration-free environment and precise handling tools, which can be expensive.
• Inverted Microscope for Neuroscience:
  • Pros: Used to study neurons, their connections, and activities. Supports advanced imaging techniques and live-cell imaging.
  • Cons: May require specialized fluorescence filters and techniques for specific research needs, which adds complexity and cost.

For industrial and material science applications

• Metallurgical Inverted Microscope:
  • Pros:Used to examine the internal structure of larger materials like metal parts.
  • Cons:Designed for flat, polished samples, not living cells or cultures.

  Inverted Microscope 5x 10x 20x 40x

  Model	BFM-52
  Eyepiece	WF10×/22
  View Head	Trinocular Viewing Head Inclined at 45°, Interpupillary 53-75mm
  Objective	Infinite Plan Achromatic Objectives 10x,20x,40x, Infinite Plan Achromatic Objectives Contrast 20x
  Fluorescence Accessories	UV Excitation Light: 330-380nm B Excitation Light: 460-490nm G Excitation Light: 510-550nm
  Focusing System	Coaxial Coarse and Fine Adjustment, Fine Division 2um
  Nosepiece	5-hole Nosepiece
  Stage	Double Layers Mechanical Stage 227mmx208mm/ 77mmx114mm
  Transmission Lighting System	Push-pull plate phase contrast condenser
  LED light, adjustable
  Camera Port	1XC
  Power Supply	100-240V 50-60Hz

  Inverted Microscope 5x 10x 20x 40x
