Medical Waste Integrated Sterilizer And Shredder
The medical waste integrated shredder and sterilizer is suitable for laboratories, dialysis centers, clinics and hospitals. Thi shealth-care facilities use only steam and electricity to process highly infectious hospital waste on site, such as wastebags, cardboard or rigid containers containing all kinds of surgical, medical and research and healthcare waste, like sharps,gloves, labware, glass, plastic/rubber tubing, filters etc. without emitting harmful substances. Basically, the entire process isautomatic except for manually taking the sterilized waste from sterilizer to the shredder, depending on the capacity, the total cycle time can be as fast as 30-60 minutes, with up to 30 Liter of medical waste can be processed.

Integrated Autoclave With Shredder
After being treated, the hospital waste is fragmented, non-toxic and therefore safe to be disposed of as regular municipal waste.The high grade stainless steel vessel conforms to the Pressure Equipment Directive and the industrial shredder is cross-cut two shaft shredder with powerful shredding blades that can automatically reverse to clean the jammed waste to reduce the size and volume of the waste down to 20%. The steam is produced by a internal steam generator and draining system as standard accessories.

Integrated Autoclave With Shredder
The system includes a simple control panel, the sterilizing time, chamber temperature, chamber pressure and waste sterilization status can be manual setting. The control system ensures high reliability, simplicity, safety of operation and automatic biomedical waste process cycles.

The medical waste integrated shredder and sterilizer have numerous safety features including a safety valve, thermostat, temperature sensors, a water level detector, pressure sensors, cutter automatic reverse and software safety features. The machine meets the highest standards for machinery, quality, safety and operation.

Product Model
Model AS30
Shredder Part Steriliser Part

Motor Power 2.2 KW. Heating Power 3 KW
Chamber Size 326x216x165 Sterilisation Temperature. +5-134℃ Optional
Rotor-Knives Dia. Φ176 mm. Heat Preservation Time 1-99.59 min/h
Rotor-Knives Thickness 15 mm. Temperature Difference Inside < 1 ℃
Shaft Speed 22 Rpm. Chamber Size Ø 388 x 300
Rotor-knives Number 14 Pcs Chamber Volume 35 L
Suggest Material Feeding Size 250×250 mm Sterilisation pressure. ≤ 0.17 Mpa.
Auto Reverse To Clear The Jammed Material Yes Microbial Inactivation. 99.99%
Output Flakes Size. < 30 mm Process: Sterilisation prior to Shredding
Whole Machine
Machine Size 1300x700x1200 mm
Machine Weight 450 KG
Working Voltage 220V/50Hz/1 Phase or Customised
