Technical Parameters
| Model | DM-125 | |
| Optical System | Finite Optical System | √ |
| Eyepiece | WF10X/18 | √ |
| Viewing Head | Monocular Head Inclined at 30° | |
| Seidentopf Binocular Viewing Head Inclined at 30°, Interpupillary 48~78mm |
√ | |
| Seidentopf Trinocular Viewing Head Inclined at 30°, Interpupillary 48~78mm |
||
| Digital Viewing Head Inclined at 30°, Interpupillary 48-78mm, 5M pixels, Support Wifi | ||
| Digital Viewing Head Inclined at 30°, Interpupillary 48-78mm, 5M pixels, 8’’ LCD, Android OS | ||
| Achromatic Objective | 4X N.A=0.1 WD=17 | √ |
| 10X N.A=0.25 WD=7 | √ | |
| 40X N.A=0.65 WD=0.53 | √ | |
| 100X N.A=1.25 WD=0.13 | √ | |
| Nosepiece | Backward Quadruple Nosepiece | √ |
| Stage | Double Layers Mechanical Stage 140x140mm, Moving Range 75x50mm | √ |
| Condenser | NA 1.25 Abbe Condenser | √ |
| Dark Field Condenser (Dry, Oil) | ||
| Focusing System | Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Division 25mm |
√ |
| Illumination | S-LED Illumination | |
| S-LED Illumination with Recharger | √ | |
| Kohler Illumination | ||
| ECO Function | ||
| Plane-cancave Mirror | ||
| Fluorescent Attachment | Fluorescent Illumination, LED Lamp | |
| Fluorescent Illumination, 100W HBO Lamp | ||
| Power Supply | AC110/220V±10%,50/60Hz | √ |
| Accessories | Polarization Set | |
| Phase Contrast Kit | ||
| Optional Accessories | LED/LCD Screen,camera | |
| Gross Weight | 8.5kg | √ |
| Weight | 9 kg |
|---|---|
| Dimensions | 20 × 20 × 55 cm |
